| ATA 系列悬挂减速机:ATA Series shaft mounted gearbox reducer. |
 |
Details |
| ATA Series shaft mounted gearbox reducer. P: 1.1~193KWi:5~31.T2N:180~17000N.mFeatures:Use low-carbon alloyed steel cementation processing completely.The gear and gear shaft precision is high.Small size and ratio,high output speed, less energy loss, low noise.Mounting Mode:Shaft mounted,Input mode: Solid shaft in put.Output mode:Hollow out-put shaft. |
|
|
| SK/SKA/SKF减速机:HELICAL-BEVEL GEAR REDUCER |
|
Details |
| SK series helical-bevel gear units overview: ◆ Right-angled output, structure compact, rigid tooth flank carrying greater torque, high precision gear ensuring unit to operate stably, noice low, lifetime long .◆ Mounting mode: Foot-mounted,flange-mounted,torque arm-mounted,small flange-mounted.◆ Input mode:direct-motor-connected,strap-connected,flange-connected.◆ Output mode: Hollow shaft output or solid shaft output, average efficiency 94%.◆ Ratio: ratio of basic type is 8.1-191,ratio of combination is up to 13459. |
|
|
| SR/SRF/SRX减速机:HELICAL GEAR REDUCER |
|
Details |
| SR series Helical gear units overview: ◆ Horizontal deviation of input shaft to output shaft is small, take full advantage of gearboxspace, 2-stage gear and 3-stage gear is in the same box.◆ Box of SR series reducer is unitary, so its structure rigidity is good, strength of shaft and lifetime of bearing is improved.◆ Mounting mode:foot-mounted, flange-mounted,there are big flange and small flange so select easily.◆ Solid output shaft, average efficiency:2-stage 96%, 3-stage 94%, combination 85%.◆ Ratio:ratio of 2-stage is5-24.8,ratio of 3-stage is 27.2-264,ratio of combination is up to18125.◆ For 2-stage basic type geared ,rotation direction of input shaft is the same that of out... |
|
|
|
